Pulsar Thermion Duo DXP50 Multispectral Thermal Imaging Riflescope

SKU
PU-76571
Rating:
0%
(0)
Reward Points
:
2990
£3,589.00 £2,990.83
Free UK Delivery*
Advice & Support Call 01642 931329 or contact us
Price Match We won't be beaten, let us know
Pulsar Thermion Duo DXP50 Multispectral Thermal Imaging Riflescope

The Pulsar Thermion Duo DXP50 Multispectral Thermal Imaging Riflescope is Pulsar’s first multispectral weapon scope. It combines 4K full-colour digital imaging and infrared imaging to create a weapon scope capable of delivering sharp, detailed pictures even in challenging conditions and is suitable for use during the day and night. To this end, it includes a full-colour 4K digital CMOS sensor, <25mK thermal sensor with a 640 x 480px resolution, and a high-aperture F50/1.0 germanium lens. It offers a thermal detection range of 1800m (for a 1.8m-tall object); advanced image processing algorithms; eight thermal colour palettes; variable magnification; and four imaging modes (Digital, Thermal, Low-light, and Picture-in-Picture). Images and videos may be captured and saved to the internal 16Gb memory. Media may be transferred or streamed wirelessly to a smartphone/tablet with the Stream Vision 2 App installed. The Pulsar Thermion Duo DXP50 Multispectral Thermal Imaging Riflescope also includes an array of shooting functions such as One-shot Freeze Zeroing; ten reticle shapes available in nine colours; and the capacity to save up to five shooting profiles each with ten zeroing distances. Finally, the Pulsar Thermion Duo DXP50 Multispectral Thermal Imaging Riflescope is housed in a classic 30mm housing; is recoil resistant up to 12-gauge, 9.3x64, .375H&H; and is powered by a built-in rechargeable 4.9Ah battery and removable rechargeable 2Ah battery. The Pulsar Thermion Duo DXP50 Multispectral Thermal Imaging Riflescope is an effective daytime and night-time weapon scope.

Pulsar Thermion Duo DXP50 Multispectral Thermal Imaging Riflescope Key Features

  • Pulsar’s first multispectral weapon scope
  • An effective daytime and night-time riflescope
  • Full-colour 4K digital CMOS sensor
  • Captures clear, detailed digital images/footage of targets at distances of 10m+
  • <25mK thermal sensor
  • IR resolution: 640 x 480px
  • High-aperture F50/1.0 germanium lens
  • Focussing wheels on either side of the weapon scope
  • Long thermal detection range: 1800m (for a 1.8m-tall object)
  • Advanced image processing algorithms improve contrast, clarity, and detail
  • Smoothing filter and brightness and contrast settings ensure comfortable observation over prolonged periods
  • Four observation modes: Digital, Thermal, Low-light, and Picture-in-Picture
  • Equal thermal and digital field of view
  • Equal thermal and digital variable magnification
  • 8 selectable thermal colour palettes
  • Photo and video recording
  • Internal 16GB memory
  • Built-in 2.4GHz and 5GHz Wi-Fi channels
  • Compatible with Pulsar’s Stream Vision 2 App
  • One-shot freeze zeroing
  • Save up to five shooting profiles each with ten zeroing distances
  • Ten reticle shapes available in nine colours
  • Classic 30mm housing
  • IPX7 waterproof rated
  • Recoil resistant up to 12-gauge, 9.3x64, .375H&H
  • Frost-resistant, quick-response HD AMOLED display
  • Operating temperature range: -25°C to +50°C
  • Wide-angle eyepiece (29.5°C)
  • Built-in 4.9Ah rechargeable battery
  • Removable 2Ah rechargeable battery
  • Operating time: 6 hours
  • Instant, four-second start up
  • An effective daytime and night-time weapon scope

What’s Included?

  • Pulsar Thermion Duo DXP50 Multispectral Thermal Imaging Riflescope

Pulsar Thermion Duo DXP50 Multispectral Thermal Imaging Riflescope Technical Specifications

Main
Sensor 640x480 pix. @ 17 µm (thermal) | CMOS 3840x2160 (digital)
Objective lens F50/1.0 (thermal) | F17/4.34 (digital)
Magnification, x 2 – 16 (for both channels)
Field of view (HxV), degrees / m@100m 12.4x9.3 / 21.8x16.4 (for both channels on minimal magnification)
Detection range, m 1800 (thermal detection)
Sensor
Type Uncooled (thermal) | Full-color CMOS (digital)
Resolution, pixels 640x480 (thermal) | 3840x2160 (digital)
Pixel pitch, µm 17 (thermal)
NETD, mK <25
Frame rate, Hz 50
Optics
Objective lens F50/1.0 (thermal) | F17/4.34 (digital)
Magnification, x
2 – 16 (for both channels)
Field of view (HxV), degrees / m @ 100 m 12.4x9.3 / 21.8x16.4 (for both channels on minimal magnification)
Eye relief, mm 50
Display
Type AMOLED HD
Resolution, pixels 1024x768
Range Performance
Detection range, m 1800 (thermal detection)
Reticle
Click value, H/V, mm at 100 m
21.25 / 21.25 (thermal channel) | 21.26 / 21.26 (digital channel)
Click range, H/V, mm at 100 m
4250 / 4250 (thermal channel) | 4252 / 4252 (digital channel)
Number of preloaded reticles
10
Video Recorder

Video / photo resolution, pixel
1024x768
Video / photo format
.mp4 / .jpg
Built-in memory, GB
16
Wi-Fi
Wireless Protocol
Wi-Fi
Wireless Standard
IEEE 802.11 b/g/n/ac (WPA)
Frequency, GHz
2.4 / 5
Environmental Characteristics
Degree of protection, IP code (IEC60529)
IPX7
Operating temperature range, °С
-25 – +50
Connections & Compatibilities
Max. recoil power on rifled weapon (Eo), Joules
6000
Shock resistance on the smooth-bore rifles, caliber
12
Compatible mounts
Standard 30 mm rings
Supported Application
Stream Vision 2
Power Supply
Output voltage, V
3.0 – 4.2
Battery type
Li-Ion Battery Pack АPS2 (external) + Li-Ion Battery Pack APS5 (internal)
Capacity, mAh
2000 (external) + 4900 (internal)
Operating time on battery pack (at t=22°C), h *
6
External power supply, V
5V, 9V (USB Type-C Power Delivery)
Weight & Size

Body material
Aluminum alloy
Dimensions, mm
420x78x83.5
Weight, kg
0.96 (batteries included)
Pulsar Thermion Duo DXP50 Multispectral Thermal Imaging Riflescope - Reticle Catalogue Manuals & Guides

Reviews

Additional Information
SKU PU-76571
Manufacturer Part Code PUL-76571
